Sale!

3PCS DRV8871 DC Motor H-Bridge DC Drive Breakout Board 6.5V-45V 3.6A MaxH-Bridge Brushed DC Motor Driver Breakout Board PWM Control for Arduino

    Original price was: $19.79.Current price is: $12.59.

    Simple 3PCS DRV8871 DC Motor H-Bridge DC Drive Breakout Board 6.5V-45V 3.6A MaxH-Bridge Brushed DC Motor Driver Breakout Board PWM Control for Arduino US Outlet

    820 in stock

    SKU: 7LIx2uv7 Categories: , Tags: , , ,

      3PCS DRV8871 DC Motor H-Bridge DC Drive Breakout Board 6.5V-45V 3.6A MaxH-Bridge Brushed DC Motor Driver Breakout Board PWM Control for Arduino

    • DRV8871 DC Motor Drive Module for Brushed DC Motor; The DRV8871 device has advanced currentregulation circuitry that does not use an analog voltage reference or external sense resistor. This novel solution uses a standard low-cost, low-power resistor to set the current threshold. The ability to limit current to a known level can significantly reduce the system power requirements and bulk capacitance needed to maintain stable voltage, especially for motor startup and stall conditions.
    • RV8871 H-Bridge Brushed DC Motor Driver Breakout Board For Arduino PWM Control 3.6A Max Internal Current Sense 6.5V To 45V
    • The DRV8871 device is a brushed-DC motor driver for printers, appliances, industrial equipment, and other small machines. Two logic inputs control the Hbridge driver, which consists of four N-channel MOSFETs that can control motors bidirectionally with up to 3.6-A peak current. The inputs can be pulsewidth modulated (PWM) to control motor speed, using a choice of current-decay modes. Setting both inputs low enters a low-power sleep mode.
    • Application:Printers; Appliances; Industrial Equipment; Other Mechatronic Applications;
    • 3.6A DC Motor H-bridge PWM Driver Module
